Hewlett Packard Enterprise - HPE ProLiant DL20 Gen11 Performance

Server - rack-mountable 1U - 1-way - 1 x Xeon E-2434 / up to 5 GHz - RAM 16 GB - SATA - hot-swap 2.5" bay(s) - no HDD - Matrox G200 - Gigabit Ethernet - no OS - monitor: none

Hewlett Packard Enterprise
P65395-B21
0190017686554
N/A
New

Price: $1,464.00

MSRP: $3,765.00
Total Available: 6

Product Description

Additional Details

What's Included

Specifications

Main Specifications
Product Description HPE ProLiant DL20 Gen11 Performance - rack-mountable Xeon E-2434 3.4 GHz - 16 GB - no HDD
Type Server - rack-mountable
Height (Rack Units) 1U
Localization Region: Americas, Asia Pacific
Server Scalability 1-way
Processor 1 x Intel Xeon E-2434 / 3.4 GHz (up to 5 GHz, (Quad-Core)
Processor Main Features Intel Turbo Boost Technology 2, Intel Smart Cache
Cache Memory 12 MB L3 cache
Cache Per Processor 12 MB
RAM 16 GB (installed) / 128 GB (max) - DDR5 SDRAM - ECC
Storage Controller SATA (SATA 6Gb/s) (Intel VROC SATA Software RAID)
Server Storage Bays Hot-swap 2.5"
Hard Drive No HDD
Optical Storage No optical drive
Graphics Controller Matrox G200
Video Memory 16 MB
Networking 1GbE
Power Redundancy Optional
OS Provided No operating system
Software Included HPE iLO Management, HPE Intelligent Provisioning
Dimensions (WxDxH) 17.1 in x 14.9 in x 1.7 in
Weight 19.84 lbs
Environmental Standards ENERGY STAR Qualified
Manufacturer Warranty Limited warranty - parts and labor - 3 years - on-site - response time: next business day
General
Type Server
Product Form Factor Rack-mountable - 1U
Built-in Devices LED panel
Embedded Security Trusted Platform Module (TPM 2.0) Security Chip
Server Scalability 1-way
Hot-Swap Bays Qty 4
Localization Region: Americas, Asia Pacific
Expansion / Connectivity
Bays 4 (total) / 4 (free) x hot-swap 2.5" SFF ¦ 1 (total) / 1 (free) x external
Slots 1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x16 mode) ¦ 1 (total) / 1 (free) x Open Compute Project mezzanine (OCP) 3.0
Interfaces 1 x HPE iLO - Type A (1 in front) (service port) ¦ 5 x USB 3.2 Gen 1x1 - Type A (1 front, 4 rear) ¦ 2 x USB 3.2 Gen 2x2 (2 internal) ¦ 1 x DisplayPort ¦ 1 x VGA ¦ 4 x LAN (Gigabit Ethernet) - RJ-45
Manufacturer Warranty
Service & Support Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Miscellaneous
Included Accessories 3 performance single rotor non-hot plug and non-redundant fans, HPE Short Friction Rail kit
Compliant Standards AES, Triple DES, ACPI 6.3, SMBIOS 3.2, Redfish API, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Active Directory v1.0, UEFI 2.9, PCI DSS, FIPS 140-2, IPv6 Ready, WEEE 2002/95/EC, EU Lot 9
RAM
Installed Size 16 GB (installed) / 128 GB (max)
Technology DDR5 SDRAM - ECC
Effective Memory Speed 4800 MHz
Rated Memory Speed 4800 MHz
Form Factor DIMM 288-pin
Slots 4 (total) / 3 (empty)
Features HPE Standard Memory, unbuffered
Configuration Features 1 x 16 GB
Networking
Ethernet Ports 4 x Gigabit Ethernet
Ethernet Controller Broadcom BCM5719
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol IPMI 2.0, SNMP 3
Features ACPI support, PXE support, Wake on LAN (WoL)
Power
Device Type Power supply - hot-plug
Power Redundancy Optional
Power Redundancy Scheme 1+1 (with optional power supply)
Installed Qty 1
Max Supported Qty 2
Voltage Required AC 100-120/200-240 V
Power Provided 800 Watt
80 PLUS Certification 80 PLUS Platinum
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 8 - 90% RH (non-condensing)
Sound Emission 27 dBA
Storage Controller
Type SATA
Controller Interface Type SATA 6Gb/s
Storage Controller Name Intel VROC SATA Software RAID
RAID Level RAID 1, RAID 0, RAID 5, RAID 10
Cache Memory
Installed Size L3 cache - 12 MB
Cache Per Processor 12 MB
Optical Storage
Type No optical drive
Monitor
Monitor Type None.
Graphics Controller
Graphics Processor Matrox G200
Video Memory 16 MB
Video Interfaces DisplayPort, VGA
Operating System / Software
OS Provided No operating system
OS Certified Microsoft Windows Server 2019, Microsoft Windows Server 2022, VMware ESXi 8.0 update 2
Software HPE iLO Management, HPE Intelligent Provisioning
Hard Drive
Type No HDD
Dimensions & Weight
Width 17.1 in
Depth 14.9 in
Height 1.7 in
Weight 19.84 lbs
Processor / Chipset
CPU Intel Xeon E-2434
Clock Speed 3.4 GHz
Max Turbo Speed 5 GHz
Number of Cores Quad-Core
CPU Qty 1
Max CPU Qty 1
CPU Upgradability Upgradable
Processor Main Features Intel Turbo Boost Technology 2, Intel Smart Cache
Chipset Type Intel C262
Sustainability Information
ENERGY STAR Certified Yes
ENERGY STAR Version 4.0
