Hewlett Packard Enterprise - HPE ProLiant DL320 Gen11

Server - rack-mountable 1U - 1-way - 1 x Xeon Silver 4410Y / up to 3.9 GHz - RAM 16 GB - SATA/SAS - hot-swap 2.5" bay(s) - no HDD - Gigabit Ethernet - no OS - monitor: none

Hewlett Packard Enterprise
P57687-B21
0190017619286
N/A
New

Price: $3,529.00

MSRP: $12,036.00
Total Available: 29

Product Description

Additional Details

What's Included

Specifications

Main Specifications
Product Description HPE ProLiant DL320 Gen11 - rack-mountable Xeon Silver 4410Y 2 GHz - 16 GB - no HDD
Type Server - rack-mountable
Height (Rack Units) 1U
Server Scalability 1-way
Processor 1 x Intel Xeon Silver 4410Y / 2 GHz (up to 3.9 GHz, (12-core)
Processor Socket LGA4677 Socket-E
Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2
Cache Memory 30 MB L3 cache
Cache Per Processor 30 MB
RAM 16 GB (installed) / 2.04 TB (max) - DDR5 SDRAM - Advanced ECC
Storage Controller RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) - OCP (HPE MR408i-o Gen11 SPDM)
Server Storage Bays Hot-swap 2.5"
Hard Drive No HDD
Optical Storage No optical drive
Video Memory 16 MB
Networking 1GbE
Power Redundancy Optional
OS Provided No operating system
Dimensions (WxDxH) 17.1 in x 23.8 in x 1.7 in
Weight 26.46 lbs
Environmental Standards ENERGY STAR Qualified
Manufacturer Warranty Limited warranty - parts and labor - 3 years - on-site - response time: next business day
General
Type Server
Product Form Factor Rack-mountable - 1U
Built-in Devices LED panel
Embedded Security Trusted Platform Module (TPM 2.0) Security Chip
Server Scalability 1-way
Hot-Swap Bays Qty 8
Expansion / Connectivity
Bays 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots 2 (total) / 2 (free) x PCIe 5.0 x16 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode)
Interfaces 1 x HPE iLO (1 in front) (service port) ¦ 3 x USB 3.2 Gen 1 (1 front, 2 rear) ¦ 1 x USB 2.0 ¦ 1 x VGA ¦ 2 x LAN (Gigabit Ethernet)
Manufacturer Warranty
Service & Support Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Miscellaneous
Included Accessories 5 x standard fans, HPE Easy Install Rails without CMA
Compliant Standards AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.3
RAM
Installed Size 16 GB (installed) / 2.04 TB (max)
Technology DDR5 SDRAM - Advanced ECC
Effective Memory Speed 4000 MHz
Rated Memory Speed 4800 MHz
Form Factor DIMM 288-pin
Slots 16 (total) / 15 (empty)
Features Registered, 8-channel memory architecture, HPE SmartMemory
Configuration Features 1 x 16 GB
Networking
Ethernet Ports 2 x Gigabit Ethernet
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol SNMP 3, IPMI 2.0
Remote Management Controller Integrated Lights-Out 6
Features Wake on LAN (WoL), ACPI support, PXE support
Power
Device Type Power supply - hot-plug
Power Redundancy Optional
Power Redundancy Scheme 1+1 (with optional power supply)
Installed Qty 1
Max Supported Qty 2
Voltage Required AC 100-240 V
Power Provided 500 Watt
80 PLUS Certification 80 PLUS Platinum
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 8 - 90% RH (non-condensing)
Storage Controller
Type 1 x RAID - OCP
Controller Interface Type Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name HPE MR408i-o Gen11 SPDM
Channel Qty 8
RAID Level RAID 0, RAID 1, RAID 5, RAID 10, RAID 50, RAID 60
Buffer Size 4 GB
Cache Memory
Installed Size L3 cache - 30 MB
Cache Per Processor 30 MB
Optical Storage
Type No optical drive
Monitor
Monitor Type None.
Graphics Controller
Video Memory 16 MB
Video Interfaces VGA
Operating System / Software
OS Provided No operating system
OS Certified CentOS, Microsoft Windows Server 2019, Microsoft Windows Server 2022, Red Hat Enterprise Linux 8.6, Ubuntu 22.04 LTS, Red Hat Enterprise Linux 9.0, SUSE Linux Enterprise Server 15 SP4, VMware ESXi 7.0 update 3, VMware ESXi 8.0, VMware ESXi 8.0 update 1
Hard Drive
Type No HDD
Dimensions & Weight
Width 17.1 in
Depth 23.8 in
Height 1.7 in
Weight 26.46 lbs
Processor / Chipset
CPU Intel Xeon Silver 4410Y
Clock Speed 2 GHz
Max Turbo Speed 3.9 GHz
Number of Cores 12-core
CPU Qty 1
Max CPU Qty 1
CPU Upgradability Upgradable
Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2
CPU Socket LGA4677 Socket-E
Chipset Type Intel C741
Sustainability Information
ENERGY STAR Certified Yes
